OMICRON COMPRESSION FITTINGS
OMICRON PUSH-FIT SERIES PN16
Plas-Fit UK offer a complete range of Omicron push-fit fittings from sizes 20mm to 32mm designed for conveyance of fluids, gaseous fuels, compressed air, chemical solutions and slurries under high pressure.
Our push-fit fittings comply with all relevant international standards in terms of dimensions and mechanical properties. Our Omicron fittings are produced in accordance with national and international standards and regulations for health and safety making them ideal for the conveyance of potable water and fluids for human consumption.
To ensure that all requirements of standards and regulations are fulfilled, our fittings are tested regularly and approved worldwide by the main testing institutes and certification bodies. All the push-fit range is DVGW approved, 16 bars rated and complies with all relevant international standards related to compression fittings.
Features
• Range of fittings from 20 mm up to 32 mm for all fittings
• Anti-vandal and security design features
• Free of assembly tools
• Closed-type fitting ensuring single-movement installation
• Demountable if needed by use of special wrench
• Designed for an extensive lifespan
• Abrasion and chemical resistant
• Conforms to international hygiene and sanitary requirements
Quality Management
The complete range of push-fit fittings have been tested and approved by all leading certification bodies, including DVGW (D), KIWA (NL), WRAS (GB), BV (AUS) and many others worldwide. Furthermore, Plas-Fit UK fittings have product certifications on all related standards such as ISO 14236, EN 12201, DIN 8076 and AS/NZS 4129.
Operating Pressure
Push-Fits are suitable for working pressures up to 16 bar @ 20⁰C.
Dimensions and Characteristics
Our fittings comply with the dimensional requirements and characteristics of the following relevant standards: EN 712 / 713 / 715 / 911 – ISO 3458 / 3459 / 3501 / 3503 ISO 14236 – DIN 8076 (Performance Series).
Threading
Threads (BSP) are manufactured according to: ISO 7, DIN 2999 and BS 21.
Resistance to Impact
The thermoplastic materials used for manufacturing the fittings have excellent impact properties.
Abrasion Resistance
The fittings are suitable for the transportation of abrasive slurries and will withstand normal conditions found in urban, mining, industrial, rural water and waste water systems.
Effect on Water
Water is essential to health and to the preservation of the environment. Water quality is commonly defined by its physical, chemical, biological and aesthetical (appearance and smell) characteristics. ELYSÉE fittings fully conform to international hygiene and sanitary requirements specified by standards such as BS6920 (UK), KTW (DE) and AUS/NZ 4020 (AUS).
Application Fields
Our fittings are suitable for joining high and low density polyethylene pipes (PE-HD, PE-LD, PE40, PE63, PE80, PE100) conforming to: EN 12201 – ISO 3607 / 14236 – DIN 8072 / 8074.
Testing of Fittings
-Testing of raw material (MRS value)
– Internal pressure test of fitting body
– Pull-out test of fittings connected with PE-pipes
– Internal pressure test of fitting fixed with PE-pipes
– Leak tightness against low pressure
– Leak tightness under bending
– Melt mass-flow rate (MFR)
– Hygienic testing of fitting’s body and sealing ring
